10.4 inch embedded industrial control screen(model GQ)

——Size: 10.4 inches (4:3)；——Screen type: LED liquid crystal screen (a-Si TFT-LCD WLED backlight) specification A；——Brightness: 250cd / m2；——Color quantity: 262K / 16.2M (6-bit / 6-bit + FRC)；——Color temperature: 6485k；——Refresh frequency: 60Hz；——Power supply voltage: 3.3V；——Display area: 211 (W) * 158.5 (H) mm；——Resolution: 1024 * 768；——Response time: 14 / 11 (typ.) (TR / TD) MS；——Visual angle: wide viewing angle 80 / 80 / 80 / 80 (typ.) (CR ≥ 10) (left / right / up / down)；——Contrast: 1000:1；——Signal access: LVDS

——Touch technology: projection capacitor technology；——Touch points: standard 10 point touch, which can realize multi-point touch functions such as enlarging and reducing pictures；——Communication mode: full speed USB 2.0, 3.0；——Theoretical hits: > 35 million；——Scanning accuracy: 4096 × four thousand and ninety-six；——Glass hardness: chemical toughened, Mohs 6 explosion-proof glass；——Drive: no drive, plug and play；——Anti light interference: normal use of sunlight, incandescent lamps, fluorescent lamps and other strong light changes

——Touch mode: pressure sensing；——Touch points: single point；——Communication mode: full speed USB 2.0, 3.0；——Theoretical hits: > 35 million；——Touch screen resolution: 2048 × two thousand and forty-eight；——Surface hardness: ≥ 3H；——Drive: no drive, plug and play；——Touch screen transmittance: ≥ 78%；——Touch sensing force: 75g (pen tip or finger touch)
